🦈 The Artiphishell Awakening

This blog post has been long overdue, but I finally found some time to sit down and help somebody here at UCSB redeploy our beast: Artiphishell. After that experience, I thought it would be a good idea to “open source” the process so that anyone around the world can experiment with and customize it.

In this post, I’ll share a step-by-step tutorial on how to deploy one of the Cyber Reasoning Systems that competed in the legendary DARPA AIxCC.

So grab a cup of coffee (or tea, or yerba mate, or whatever keeps you awake) and let’s dive in! ☕😄

⚠️ Disclaimer: Although this tutorial has been successfully replicated by several people, it’s still far from perfect. If you notice any inaccuracies or missing steps, please let me know at degrigis@ucsb.edu or on X (@degrigis). Thank you!

💻 Requirements

We have tested the deployment on a box with these specs:

No LSB modules are available.
Distributor ID: Ubuntu
Description:    Ubuntu 22.04.5 LTS
Release:        22.04
Codename:       jammy

Linux myserver 5.15.0-153-generic #163-Ubuntu SMP Thu Aug 7 16:37:18 UTC 2025 x86_64 x86_64 x86_64 GNU/Linux

(aixcc) ~/projects$ python --version
Python 3.10.12

And, importantly,

(aixcc) ~/projects$ yq --version
yq (https://github.com/mikefarah/yq/) version v4.30.8

📣 Warnings

⚠️ I would strongly encourage using a machine dedicated to this. DO NOT deploy Artiphishell on your local laptop or on a machine where you store important data

⚠️ You will need to set up a LiteLLM with your own LLM keys. Be very mindful of this, Artiphishell can be very expensive if you leave it run for long time (or forget about it running in some box). Set limits to these keys and make sure you shut everything down whenever you are done with it.

📖 Instructions

[1] First, let’s download the AIxCC release from here. After that, git clone http://github.com/degrigis/artiphishell-tweaks.git. The latter are files you will use to replace the ones in the Artiphishell-Finals folder (i.e., a few tweaks are necessary to make Artiphishell deployable on your box). From now on, we are gonna assume the working directory is going to be ~/artiphishell-Finals.

[2] Make sure you have this specific version of yq installed:

~/artiphishell-release$ yq --version
yq (https://github.com/mikefarah/yq/) version v4.30.8

You can find it here: https://github.com/mikefarah/yq/releases/tag/v4.30.8

[3] Download the artiphishell-tweaks and use the files in it to overwrite the files in artiphishell-Finals . (The artiphishell-tweaks respect the folders’ structure of the artiphishell-Finals folder)

[4] Build all the base images:

~/artiphishell-Finals$ ./local_run/rebuild_base_images.sh

After this step, if you do docker image ls | grep aixcc you should see something like:

ghcr.io/shellphish-support-syndicate/aixcc-afc-competition-api                         latest                                    d913f660cc3c   47 seconds ago      7.66GB
aixcc-afc-competition-api                                                              latest                                    d913f660cc3c   47 seconds ago      7.66GB
aixcc-libs                                                                             latest                                    3ad045b94110   2 minutes ago       78.1MB
ghcr.io/shellphish-support-syndicate/aixcc-libs                                        latest                                    3ad045b94110   2 minutes ago       78.1MB
aixcc-data                                                                             latest                                    0cb410294698   2 minutes ago       136MB
ghcr.io/shellphish-support-syndicate/aixcc-data                                        latest                                    0cb410294698   2 minutes ago       136MB
aixcc-component-base                                                                   latest                                    98a76033d6cb   3 minutes ago       9.83GB
ghcr.io/shellphish-support-syndicate/aixcc-component-base                              latest                                    98a76033d6cb   3 minutes ago       9.83GB
aixcc-dependencies-base                                                                latest                                    abddafffffe7   3 hours ago         7.34GB
ghcr.io/shellphish-support-syndicate/aixcc-dependencies-base                           latest                                    abddafffffe7   3 hours ago         7.34GB
aixcc-codeql-server

[5] Now, Create a new Python virtual environment (e.g., aixcc) and install pydatatask

(aixcc) ~/artiphishell-Finals/libs/pydatatask$ pip install -e .

[6] Install also crs-telemetry

(aixcc) ~/artiphishell-Finals/libs/crs-telemetry$ pip install -e .

[7] Pull the aixcc-base-runner:

docker pull ghcr.io/aixcc-finals/base-runner:v1.3.0

[8] Run the local build

(aixcc) ~/artiphishell-Finals$ ./local_run/rebuild_local.sh build-all

[9] The building happens in parallel, and some dependencies between containers might break at this step. If you see errors such as:

------
 > [image-aixcc-submitter stage-1  8/11] RUN --mount=type=cache,target=/root/.cache/uv     uv sync --no-install-project:
36 Using CPython 3.11.0rc1 interpreter at: /usr/bin/python3.11
36 Removed virtual environment at: .venv
36 Creating virtual environment at: .venv
75   × Failed to resolve dependencies for `crs-api` (v0.1.0)
75   ╰─▶ Requirements contain conflicting URLs for package `shellphish-crs-utils`
75       in all marker environments:
75       - file:///shellphish/libs/crs-utils
75       - file:///shellphish/libs/crs-utils (editable)
75   help: `crs-api` (v0.1.0) was included because `submitter` (v0.1.0) depends
75         on `crs-api`
------
failed to solve: process "/bin/sh -c uv sync --no-install-project" did not complete successfully: exit code: 1

Just re-run the command at [9] until these errors do not appear anymore #DevOpsDoneRight.

[10] If everything build correctly, you should see a lot of containers with marked as “aixcc”

docker image ls | grep aixcc

aixcc-codeql-server                                                                    latest                                    07c2343b1ebe   About an hour ago   9.25GB
aixcc-telegraf                                                                         latest                                    892cbace18a0   About an hour ago   272MB
ghcr.io/shellphish-support-syndicate/aixcc-crs-api                                     latest                                    f1d881d2d6e0   15 hours ago        9.02GB
ghcr.io/shellphish-support-syndicate/aixcc-pdt-agent                                   latest                                    6dfa1d9d8fba   15 hours ago        9.06GB
ghcr.io/shellphish-support-syndicate/aixcc-vllm-server                                 latest                                    583e1c416b37   15 hours ago        10.8GB
ghcr.io/shellphish-support-syndicate/aixcc-telegraf                                    latest                                    cffae016d1e0   15 hours ago        272MB
aixcc-otel-collector                                                                   latest                                    86bed71c304b   15 hours ago        318MB
ghcr.io/shellphish-support-syndicate/aixcc-otel-collector                              latest                                    581ca23211ac   15 hours ago        318MB
ghcr.io/shellphish-support-syndicate/aixcc-jaeger                                      latest                                    86157c743d0d   15 hours ago        109MB
ghcr.io/shellphish-support-syndicate/aixcc-litellm                                     latest                                    593963761e61   15 hours ago        1.87GB
ghcr.io/shellphish-support-syndicate/aixcc-data-prepper                                latest                                    f4c88dd40148   15 hours ago        1.62GB
ghcr.io/shellphish-support-syndicate/aixcc-crs-monitor                                 latest                                    b1bfa1846069   15 hours ago        7.9GB
ghcr.io/shellphish-support-syndicate/aixcc-image-puller                                latest                                    30015187582e   15 hours ago        71.4MB
ghcr.io/shellphish-support-syndicate/aixcc-competition-server-infra                    latest                                    2685cefd8e43   15 hours ago        10.2GB
aixcc-aflplusplus                                                                      latest                                    5693adef0239   17 hours ago        10.4GB
ghcr.io/shellphish-support-syndicate/aixcc-aflplusplus                                 latest                                    5693adef0239   17 hours ago        10.4GB
[...]

[11] Create these folders on your machine (this needs sudo )

/shared/fuzzer_sync
/shared/docker-locks/

[12] Change permissions to the folders:

sudo chown -R your_user:your_user /shared/fuzzer_sync
sudo chown -R your_user:your_user /shared/docker-locks

[13] Change these variables in ~/artiphishell-Finals/local_run/env.sh :

export LITELLM_KEY=sk-artiphishell-da-best!!!
export AIXCC_LITELLM_HOSTNAME=${AIXCC_LITELLM_HOSTNAME:-http://wiseau.seclab.cs.ucsb.edu:666/}
export USE_LLM_API=1 # Whether to use the LiteLLM API or not for agentlib

with

export LITELLM_KEY=<YOUR_LITELLM_KEY>
export AIXCC_LITELLM_HOSTNAME=<YOUR_LITELLM_HOSTNAME>
export USE_LLM_API=1 # Whether to use the LiteLLM API or not for agentlib

For this, you will have to set up your own LITELLM server (https://github.com/BerriAI/litellm) and use your OpenAI, Anthropic keys (be mindful of that, set a limit on spending).

[14] As an example, now start Artiphishell with the sqlite target. Make sure you are running this in the virtualenv where you installed pydatatask.

(aixcc) ~/artiphishell-Finals$ ./run_artiphishell.sh https://github.com/degrigis/afc-exhibition2-sqlite3-full exhibition2-sqlite3-full

[15] - When asked:

Starting Artiphishell!
Do you want to run in DELTA mode?

Say no

[16] Wait for these logs to appear:

DEBUG | pydatatask.pipeline | 🌅 canonical_build:770d986660de9fbc2c8b461b17d1574e1077aed285183c2597071fe08032ce22#0 +20000000000.0
DEBUG | pydatatask.pipeline | 🌅 codeql_build:770d986660de9fbc2c8b461b17d1574e1077aed285183c2597071fe08032ce22#0 +20000000000.0
DEBUG | pydatatask.pipeline | 🌅 full_mode_create_analysis_source:770d986660de9fbc2c8b461b17d1574e1077aed285183c2597071fe08032ce22#0 +999999999.0
DEBUG | pydatatask.pipeline | 🌅 patcherg:770d986660de9fbc2c8b461b17d1574e1077aed285183c2597071fe08032ce22#0 +1000000.0
DEBUG | pydatatask.pipeline | 🌅 clang_index:770d986660de9fbc2c8b461b17d1574e1077aed285183c2597071fe08032ce22#0 +10000.0
DEBUG | pydatatask.pipeline | 🌅 ccache_init:770d986660de9fbc2c8b461b17d1574e1077aed285183c2597071fe08032ce22#0 +1000.0
DEBUG | pydatatask.pipeline | 🌅 request_gpu_machine:770d986660de9fbc2c8b461b17d1574e1077aed285183c2597071fe08032ce22#0 +100.0
DEBUG | pydatatask.pipeline | 🌅 coverage_build_c:770d986660de9fbc2c8b461b17d1574e1077aed285183c2597071fe08032ce22#0 +75.0
DEBUG | pydatatask.pipeline | 🌅 build_configuration_splitter:770d986660de9fbc2c8b461b17d1574e1077aed285183c2597071fe08032ce22#0 +0.0

This means that the project was sent to Artiphishell.

[17] If you want to visualize what’s happening, open another terminal and go to the root folder:

(aixcc) ~/artiphishell-Finals$ pd viz

INFO:     Application startup complete.
INFO:     Uvicorn running on http://0.0.0.0:8050 (Press CTRL+C to quit)

This spins up the visualization of Artiphishell on the machine at http://0.0.0.0:8050

If you are using a server, you can use an SSH forward to access it from your laptop’s browser.

(e.g., ssh -L 8050:localhost:8050 cimber)

[18] Open your browser and go to localhost:8050

[19] You can see all the containers running on the machine where you spin up Artiphishell with docker ps . With docker logs -f <CONTAINER_ID> you can see the logs of each component.

[20] To explore the generated artifacts, drop this script (pd-show) in the folder ~artiphishell-Finals/ (the folder where you see the “pipeline.lock” file)

(aixcc) ~/artiphishell-Finals$ ls -la
drwxrwxr-x 14 degrigis degrigis   4096 Oct 20 02:16 .
drwxrwxr-x  4 degrigis degrigis   4096 Oct 19 16:38 ..
drwxrwxr-x  5 degrigis degrigis   4096 Aug  8 17:12 aixcc-infra
-rwxrwxr-x  1 degrigis degrigis    337 Aug  8 17:12 compare-afc-crs-shellphish.sh
drwxrwxr-x 56 degrigis degrigis   4096 Oct 18 16:16 components
drwxrwxr-x  2 degrigis degrigis   4096 Aug  8 17:12 config
-rwxrwxr-x  1 degrigis degrigis    588 Aug  8 17:12 deploy-to-afc-crs-shellphish.sh
drwxrwxr-x  2 degrigis degrigis   4096 Oct 17 22:22 docker
-rw-rw-r--  1 degrigis degrigis    778 Oct 18 02:16 .dockerignore
-rw-rw-r--  1 degrigis degrigis    105 Aug  8 17:12 .gitattributes
drwxrwxr-x  4 degrigis degrigis   4096 Aug  8 17:12 .github
-rw-rw-r--  1 degrigis degrigis    534 Aug  8 17:12 .gitignore
drwxrwxr-x  9 degrigis degrigis   4096 Aug  8 17:12 infra
drwxrwxr-x 25 degrigis degrigis   4096 Aug  8 17:12 libs
-rw-rw-r--  1 degrigis degrigis   1068 Aug  8 17:12 LICENSE
drwxrwxr-x  2 degrigis degrigis   4096 Aug  8 17:12 .llm-docs
drwxrwxr-x  7 degrigis degrigis   4096 Oct 19 03:00 local_run
-rwxrwxr-x  1 degrigis degrigis   2954 Oct 20 02:16 pd-show.   //<------THIS
-rw-rw-r--  1 degrigis degrigis 133543 Oct 18 17:57 pipeline.lock //<-----THIS

The script will show you a nice table and you can see the logs/file/tars produced by the running CRS.

(aixcc) ~/artiphishell-Finals$ ./pd-show
                                                                       Pipeline Tasks Artifacts
┏━━━━━━┳━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━┳━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━┳━━━━━━━━━┳━━━━━━━━━━┓
┃ Type ┃ Repo                                                                            ┃ Basedir                                              ┃ # Files ┃ Cls      ┃
┡━━━━━━╇━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━╇━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━╇━━━━━━━━━╇━━━━━━━━━━┩
│      │ Kumushi_Java_postprocessing_main_autodone_kumushi_delta_java                    │ /tmp/pydatatask-degrigis/lock-xsecffekjc/tmp57gzf81h │ 0       │ YamlFile │
│      │ Kumushi_Java_postprocessing_main_autodone_kumushi_java                          │ /tmp/pydatatask-degrigis/lock-xsecffekjc/tmpp1t0hui0 │ 0       │ YamlFile │
│ 📖   │ Kumushi_Java_postprocessing_main_autologs_kumushi_delta_java                    │ /tmp/pydatatask-degrigis/lock-xsecffekjc/tmpb8yh1_xo │ 0       │ File     │
│ 📖   │ Kumushi_Java_postprocessing_main_autologs_kumushi_java                          │ /tmp/pydatatask-degrigis/lock-xsecffekjc/tmpg19pishl │ 0       │ File     │
│      │ Kumushi_postprocessing_main_autodone_kumushi                                    │ /tmp/pydatatask-degrigis/lock-xsecffekjc/tmpckmkg8pz │ 0       │ YamlFile │
│      │ Kumushi_postprocessing_main_autodone_kumushi_delta                              │ /tmp/pydatatask-degrigis/lock-xsecffekjc/tmpfw4y7b6f │ 0       │ YamlFile │
│ 📖   │ Kumushi_postprocessing_main_autologs_kumushi                                    │ /tmp/pydatatask-degrigis/lock-xsecffekjc/tmp5m9jtvj4 │ 0       │ File     │
│ 📖   │ Kumushi_postprocessing_main_autologs_kumushi_delta                              │ /tmp/pydatatask-degrigis/lock-xsecffekjc/tmppwozv4id │ 0       │ File     │
│      │ PatcherG_postprocessing_main_autodone_patcherg                                  │ /tmp/pydatatask-degrigis/lock-xsecffekjc/tmpzn7fql1h │ 0       │ YamlFile │
│ 📖   │ PatcherG_postprocessing_main_autologs_patcherg                                  │ /tmp/pydatatask-degrigis/lock-xsecffekjc/tmp8py7skug │ 0       │ File     │
│      │ PatcherQ_postprocessing_main_autodone_patcherq                                  │ /tmp/pydatatask-degrigis/lock-xsecffekjc/tmp_g64de0b │ 0       │ YamlFile │
│      │ PatcherQ_postprocessing_main_autodone_patcherq_delta                            │ /tmp/pydatatask-degrigis/lock-xsecffekjc/tmphv3fdbie │ 0       │ YamlFile │
│      │ PatcherQ_postprocessing_main_autodone_patcherq_from_sarif                       │ /tmp/pydatatask-degrigis/lock-xsecffekjc/tmpzlo49kwh │ 0       │ YamlFile │
│      │ PatcherQ_postprocessing_main_autodone_patcherq_from_sarif_delta                 │ /tmp/pydatatask-degrigis/lock-xsecffekjc/tmpc_vhmy6_ │ 0       │ YamlFile │

You can also docker ps , see which current components are running, and docker logs -f <docker_container_id> to see what’s going on!

[21] To shut everything down: just kill all the containers whose NAMES start with CRS___

docker kill $(docker ps -q --filter "name=^CRS__")

👀 EXTRA NOTES:

These EXTRA_ENV in the script run_artiphishell:

EXTRA_ENV='-T coverage_trace -T kumushi_delta_java -T quick_seed_delta -T submitter -T vuln_model_scan -T grammar_agent_explore_delta -T grammar_agent_explore -T grammar_guy_fuzz -T aflpp_cross_node_sync -T grammar_composer_run -T corpus_inference_trace -T corpus_inference_llm -T corpus_kickstart -T aflpp_trigger_upscale -T semgrep_analysis --global-script-env ARTIPHISHELL_CCACHE_DISABLE=1' CUSTOM_OSS_FUZZ_TARGETS_REPO=git@github.com:degrigis/artiphishell-ossfuzz-targets.git ./local_run/run_local.sh $1 $2 "" $BASE_COMMIT $REFERENCE_COMMIT

Are controlling which components are DISABLED. As in, -T coverage_trace disabled the coverage_trace task. The script comes with a few defaults. Depending on what you want to do, you may want to play with these flags.

Be mindful of your LLM keys, as said, if you run everything for hours, you might end up spending a lot of money.
Every component (in the folder components ) is configured through the pipeline.yaml . This includes the number of replicas, number of cores per components, etc… If you are running Artiphishell on your laptop, you may want to disable components and reduce replicas.

I hope this little tutorial will play its part in democratizing the development and adoption of AI-based CRSes. This technology is truly (and rapidly!) changing the way we can find and fix vulnerabilities at scale. Can you imagine a world where 0days will be SO rare because of how fast we can catch them before they hit production?! That future could be closer than we think.

Happy hacking!
